K. C. Morris

Innovation

Sustainable Manufacturing Is Smart Manufacturing

Sustainability saves resources and money. NIST’s standards for modeling manufacturing processes aims to quantify that.

Published: Wednesday, November 4, 2020 - 12:01

The Covid pandemic has highlighted the role that manufacturing plays in our society. Manufacturing is important not only for improving our quality of life but also for the necessities of life, from food to toilet paper to transportation and safe and secure housing.  As our society has evolved, we have learned better ways to manufacture and are able to create an amazing variety of products. But providing these goods is not without side effects to the environment, and care is needed to manage the impacts of our production systems.

According to the Organization for Economic Cooperation and Development (OECD), sustainable manufacturing refers to the ability to manage manufacturing operations “in an environmentally and socially responsible manner.” Standards and programs of various kinds have formed around this idea, but many only scratch the surface of what could be accomplished if we had better measurement science to really evaluate the trade offs that manufacturers must make every day to be sustainable.

Let there be no doubt that when care is not taken, manufacturing will make a mess. The response has often been regulations to require more consideration of the environment. That’s the “stick” approach to sustainable manufacturing.

It turns out that a “carrot” also exists—sustainability leads to greater resource efficiency and resulting cost savings. In addition, social pressures to show good stewardship are mounting in the form of customer demand and investor interest. These pressures have long been difficult for manufacturers to respond to in a meaningful, data-driven way, especially for the small and medium-size manufacturers that have little control over the products they produce because they are often not engaged in their design.

No one-size-fits-all solution can exist for improving sustainable manufacturing performance. Each manufacturing enterprise is unique. Even large manufacturers with multiple facilities producing the same products struggle to share performance lessons between factories. Each situation needs to be uniquely addressed based on the corporate knowledge of the manufacturer.

Several early standards efforts focused on a management perspective to help address how to best manage manufacturing facilities and other resources, but these fall short of addressing manufacturing’s core function—that of transforming raw materials into new products.

My colleagues and I knew that manufacturers needed a systematic way to dig deep into their operations to find their own environmental savings opportunities. From June 2015 to March 2016, we held a series of industry roundtables and reviewed the published literature to better understand how manufacturing processes are being measured today and the need for improvements. One thing was clear: Standards in this area were virtually nonexistent. Our goal as National Institute of Standards and Technology (NIST) researchers is to develop the measurement science to help manufacturers improve on their core function, which is accomplished with manufacturing processes.

The term “manufacturing process” is itself an abstraction that refers to many, many different types of processes, and each of those processes is unique. Our challenge was to create standard methods that could apply to all those processes in a useful way. We wanted the standards to be compatible with emerging technology to integrate the models seamlessly with the burgeoning array of communications, AI, and other tools that are the future of manufacturing—so-called smart manufacturing.

The approach we took was to define standards for applying information technology to the description, or characterization, of manufacturing processes. By providing standard methods for characterizing manufacturing processes, we enable those descriptions to be used in an automated way so that they can be reused for a variety of purposes. The building block for all the uses is a standard form for what we call a unit manufacturing process model.

Moving beyond blueprints

The unit manufacturing process model (UMP) is to a manufacturing process what a blueprint has been for a product or building design. Blueprints, so called for the backing of blue ink originally used on each page, were first introduced during the 1840s to copy a technical drawing exactly so that the information could be more widely shared. Over the years more and more standards were developed to precisely represent all kinds of technical drawings of engineered products.

Jump forward to the digital age. Now, we can collect so much more data on a design than standard blueprints can capture. In the product design world, computer-aided design, or CAD, systems are used to produce these drawings as three-dimensional models. Standards for representing these models provide an information-rich backbone to which the 3D models are “attached” in the virtual sense of the word.

For example, the standard for product model data ISO 10303 (aka STEP) defines a complex array of information that can associate the digital 3D representations with various other perspectives on product information, such as life cycle, used in other enterprise systems that integrate data across an organization.

Manufacturing processes from the physical world are represented in the virtual world through models of those processes, based on the ASTM E3012 standard highlighted in the middle of the figure. These models can be used for communication about processes, process performance optimization, process flow simulations, and life cycle impact estimation.

No such format for representing manufacturing processes has been available until now. Starting in 2013, we worked with standards development organization ASTM’s E60 committee on sustainability to form a subcommittee on sustainable manufacturing, E60.13, where we introduced the idea of a set of standards for modeling manufacturing processes—the UMP model. In 2020 the capstone of the initial set of standards was published as the Standard Guide for Characterizing Environmental Aspects of Manufacturing Processes, E3012. That effort was led by Bill Bernstein (NIST). This standard describes the UMP format.

Built on state-of-the-art information technology, the UMP model has been designed from the start to integrate into a smart manufacturing enterprise. A UMP model can be used to capture institutional knowledge about a process so that it can be more easily shared. The new manufacturing process blueprints serve not only as a means of communication but also as digital models of the processes. They can be automated for evaluation of process performance or be used with other process models to evaluate streams of potential manufacturing workflows.

A UMP model provides a uniform and precise way for manufacturers to describe their processes, enabling:
• Reliable and archivable communications about a process
• A means to establish performance baselines
• A path forward for developing simulations of manufacturing process flows
• Mechanisms for generating environmental impact assessments for manufacturing processes
• Informed decisions in analyzing trade offs between competing goals, such as manufacturing speed and use of resources such as energy and materials.

Sustainability: A balancing act

Although not all these things are possible now, the standards are a strong starting point for this work. With these basic measurement tools in place, manufacturers and researchers can reach for and experiment with greater capabilities that will give them better control over manufacturing processes and allow them to make more informed choices about trade offs. With the standards activities now underway in ASTM, a path for expanding on those standards to provide more capabilities and precision in definitions is available.

Contributions to U.S. environmental impacts from the manufacturing industry and its supply chains. The figure shows that, of the 76.6 percent of U.S. emissions driven by manufacturing production, 17 percent is directly attributed to the manufacturing sector. The remainder is driven by supporting sectors including mining, utilities, construction, and agriculture. The U.S. Energy Administration predicts the industrial sector that includes manufacturing processes will see an increase in emissions of 26 percent by 2050, while emissions of other high producing sectors will hold steady or decline.

The initial building block for the UMP model, the Standard Guide for Characterizing Environmental Aspects of Manufacturing Processes, does not exist in a vacuum. The knowledge captured in the models must be drawn from multiple sources, starting with subject matter experts and integrating with principled engineering design and analysis applications. A single UMP model encapsulates the complexity of a manufacturing process through a computational representation. Similarly, it may include a data-driven discovery effort, that is, an empirical study of the process.

Two aspects critical to a well-developed UMP representation—process improvement planning and key performance indicators—are also documented in ASTM standards:
• Establishing a process improvement project: The Standard Guide for Evaluation of Environmental Aspects of Sustainability of Manufacturing Processes, ASTM standard 2986, walks a manufacturer through establishing a performance improvement effort, including goal setting, process identification, and formulating an improvement plan using the state-of-the art plan-do-check-act approach. The project was led by Paul Witherell (NIST).
• Selecting key performance indicators: Sustainable manufacturing is the act of balancing objectives. Reducing environmental impacts must be considered along with a business’s operational capabilities and economic and performance goals. The Standard Guide on Definition, Selection, and Organization of Key Performance Indicators for Environmental Aspects of Manufacturing Processes, ASTM standard E3096, provides guidance for how to pool the collective wisdom of an organization and decide on the right things to measure and improve upon. The standard instructs manufacturers in developing unique metrics by leaning on a diversity of viewpoints to identify realistic measures for a given process improvement project. These metrics are associated with the UMP model of the process. This effort was led by Shaw Feng (NIST) with support from Michael Brundage (NIST).

Combined, these three standards support a continuous improvement process for manufacturing systems and provide standard forms for storing a manufacturer’s institutional knowledge.

Certainly, other facets of sustainable manufacturing are important for manufacturers. So far, our ASTM sustainable manufacturing subcommittee has developed two other standards to address different aspects of sustainable manufacturing, and research is underway on others. The two areas where standards have already been initiated relate to incorporating manufacturing sustainability considerations into economic analysis, led by Doug Thomas (NIST), and provide more process definitions for describing manufacturing materials for use in life-cycle analysis.

I am very proud to have led this team of talented researchers in creating this initial set of standards and laying the groundwork for the future of sustainable manufacturing. It was no small undertaking. In addition to those trailblazers listed above, we would also like to acknowledge our colleagues who helped in the efforts, including Sudarsan Rachuri, now at the Department of Energy; Kevin Lyons and Swee Leong, now retired from NIST; former NIST research associates Mahesh Mani, David Lechevalier, and Deogratias Kibira; and the team at Oregon State University working under the supervision of Karl Haapala, at George Mason University under Alex Brodsky, and at Old Dominion University under Barry Ezell.

We are interested in learning from others what new standards are needed and invite further contributions.

Fist published Oct. 2, 2020, on NIST’s Taking Measure blog.
